MECHATRONIC TRAINING COURSES

Discover our mechatronic training courses on the programming

of ECUs and TCUs and open the doors to the future

SEE WHAT MMS
HAS TO OFFER

Take part in a training session
and get up to speed

Multilingual

Theory & Practice

Coffee Break

Certificate

AUTOMOTIVE TECHNOLOGY
TRAINING COURSES

MAGICMOTORSPORT offers innovative and dynamic automotive technology training courses around the world that focus on the programming of engine and gearbox control units.

A highly qualified Team of experts offers participants customized solutions and skills needed to use MMS tools efficiently.

The training courses are divided into theory and practice and aim to develop knowledge and competence in the automotive sector.

BENEFIT FROM OUR EXPERIENCE

During these mechatronic training courses, the Team will guide you through the steps of efficient ECU and TCU programming during a
detailed seminar dedicated to the use of MMS tools and a practical hands-on workshop that allows
the participant to gain transferable skills through bench simulations.

All this supported by the consistent and multilingual MAGICMOTORSPORT quality Tech Support.

  • Introduction to the ECU
  • Types of memories and processors mounted on ECUs and TCUs
  • Boot Tricore, Tuning Protected (TPROT)
  • Hardware connections (Helpdesk search), service files
  • Programming on the Bench
  • TPROT identification, password reading and storage
  • ECU pairing
  • The Helpdesk and online services (MOD, EGR off, DPF off, IMMO off)
  • Accessories for bench programming (bench, connectors and adaptors)
  • Bench connections and Breakbox function
  • Bench testing with the entire range of MAGPro2 tools in different modes: OBD, BDM, Bootloader, transmission control unit reading and writing, pairing, unlock, antituning, simulations of lock during programming.
  • Questions and Answers
  • Software management of anti-pollution systems - introduction

EGR & particulate filters: development of a calibration strategy for the maintenance of anti-pollution systems and their disabling for racing purposes; the Switch off for the equipment substitution and the emulation of the particulate filters.

  • Data processing methods (tabular)

Analysis of the main tables with an explanation of simple methods for the processing of the identified areas.

  • Torque monitoring and torque request (level A);
  • Driver’s wish: the driver's torque request;
  • Torque conversion in injected fuel quantity;
  • Limitations of torque & injected fuel quantity;
  • Injection monitoring and injection timing (level A);
  • Injection times, Rail pressure and advanced injection timing (level A);
  • Turbo pressure & limitations;
  • Air Fuel Ratio control system

Calibration examples

Analysis and comparison of stage 1 calibration software for Bosch EDC16 & EDC17 engine control units;

  • Verification of data integrity for software programming
  • Tips on the checksum and the parity bits
  • Tips on the Cyclic Redundancy Check (CRC).

MAGPro2 Line Presentation

  • Presentation of MAGICMOTORSPORT
  • Notions on the structure of an ECU
  • MAGPro2 Line of programmers
  • Methods of programming ECUs with MMS tools
  • OBD in the vehicle and on the bench
  • BDM
  • Bootloader
  • Introduction to the Helpdesk and the use of MMS services
  • Techniques of opening an ECU (Helpdesk)
  • Use of MAGICMOTORSPORT Software
  • Overview of the MAGICMOTORSPORT programming kits

Presentation of the VVDI Tool

  • XHORSE product presentation
  • Notions on the structure of EZS, ESL and KEY
  • General notions on programmers and XHORSE products
  • EZS programming method using VVDI MB
  • EZS BGA programming method (all keys lost)
  • EZS BGA programming method (at least one working key)
  • Reading and writing in BDM of EZS with Motorola processors
  • Programming via IR
  • Use of the VVDI software
  • EZS, ESL and KEY testing techniques

MAGPRO 2 LINE PRESENTATION

  • Presentation of MAGICMOTORSPORT
  • Notions on the structure of an ECU
  • MAGPro2 Line of programmers
  • Programming methods of ECUs with the use of our tools
  • OBD in the vehicle and on the bench
  • BDM
  • Bootloader
  • Introduction to the Helpdesk and the use of our services
  • Techniques of opening an ECU (Helpdesk)
  • Use of the MAGICMOTORSPORT Software
  • Overview of MAGICMOTORSPORT products and useful programming accessories
  • Questions and Answers

INTENSIVE COURSE N ° 1 - COURSE PROGRAM

HARDWARE USED:

  • VVDI MB
  • MBE KEY EVO PROG 2
  • VVDI Prog
  • Multiprog
  • EEPROM Programmer E6
  • EIS/ESL Tool

SOFTWARE USED:

  • VVDI MB software
  • VVDI Prog Software
  • MultiProg Software
  • EEPROM programmer software
  • NEC 12
  • IR key tool Advanced software
  • ESL/EVO Prog Software

INVOLVED COMPONENTS:

  • Dashboard
  • EZS/EIS
  • ESL/ELV
  • ZGW/CGW
  • ECU and/or TCU

TESTS are carried out directly on the bench and/or on the vehicle:

  • w169 or w209 or w211 or w906 or w639
  • w204 or W207 or W212 or w246

MATERIAL FOR PARTICIPANTS:

  • Connection manuals
  • Microprocessor datasheet
  • Repair manual (ITA)
