Flex version 5.24.0.0 are ready

OBD FULL and Bench solutions for MERCEDES & INFINITI DELPHI CRD3x.x

Magicmotorsport releases a new software version of Flex (5.24.0.0) for the complete reprogramming of DELPHI CRD3 engine control units equipped with TC1797 and TC1793 microprocessors in OBD Full and Bench modes.

The new protocol for Delphi CRD3x.x allows you to work on the entire range of Mercedes engines (2.2D, 2.1D and 1.8D OM651) and allows you to carry out chip-tuning operations in total safety, thanks to the Full-Backup mode on models ranging from 2010 to 2021.

Here are some of the supported vehicles:

• Mercedes C180 (C205) 220 D
• Mercedes CLA (245) 200 CDI
• Mercedes GLA (X156) 220 D
• Mercedes Sprinter (W906) 214 CDI
• Infiniti Q70 (Y51) 220 CDI
• Mercedes A-Class (W176) 200 CDI
• Mercedes Viano (W639) 200 CDI

The new OBD & Bench protocol for DELPHI CRD3x.x is available for the following software packages:

• FLS0.1 – SW Flex ECU (cars, vans, bikes) OBD + Bench
• FLS0.10 – SW Flex Infineon TC17xx Master
• FLS0.5 – Package Flex FULL

Read time: ~ 3 minutes | Write time: ~ 1.30 minutes

New protocols added:

(OBD)

• Mercedes Delphi CRD3P.G0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.E1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.D1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.C0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.B0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.A0 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3PLUS.A0 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.F1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.E1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Infiniti Delphi CRD3.N5 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.7A TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.60 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.59 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.58 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.50 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.40 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.30 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.2R TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.20 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.1R TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.10 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup

(BENCH)

• Mercedes Delphi CRD3P.G0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.E1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.D1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.C0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.B0 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3P.A0 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3PLUS.A0 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.F1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.E1 TC1793 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Infiniti Delphi CRD3.N5 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.7A TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.60 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.59 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.58 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.50 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.40 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.30 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.2R TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.20 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.1R TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup
• Mercedes Delphi CRD3.10 TC1797 Read / Write / Checksum Internal Flash; Read External Eeprom; Full Backup

Bug fixes:

• Fixed parameters printing on MB Continental VGS2-NAG2
• Fixed blank eeprom content on BMW Continental MSD81

Software improvements:

• Added Bench option for Mercedes Delphi CRD2.x (Read/Write/Checksum Maps)
• Improved password reading for MSV80
• Added new CRC for GM DELCO E39
• Added new CRC for VOLVO BOSCH EDC17C1/2
• Added new CRC for VAG BOSCH GS19 6HP
• Added new CRC for GM DELCO E98
• Added new CRC for SUBARU DENSO SH72543

Take a look at the protocols newly added to the Flex vehicle list.
