OBD Support for Keihin Units
New release version 7.58.0.0 of Flex out now, providing OBD support for Keihin KTKS_v1 control units with RH850 processor and KHR4 with SH72531 microcontroller installed on Triumph EU4 and EU5 motorcycles.
This release allows you to work on Triumph motorbikes directly via the diagnostic port of the vehicle, simplifying reading and writing operations and ensuring quick, safe, and efficient interventions.
With this update, you now can:
Have the virtual read of the unit;
Read the map area in OBD;
Optimize engine management and throttle response;
Improve supply fluidity and efficiency.
Please note: in order to connect, you need the FLX2.68 EU5/EU5+ cable for EU5/EU5+ Bikes or the MMS03.002 adapter.
Some of the supported vehicles
Triumph Street Triple 765 R (III) 765cc (E4) [116HP] (2017MY)
Triumph Tiger 1200 XRT (I) 1215cc (E4) [139HP] (2017MY)
Triumph Tiger 800 XR (II) 800cc (E4) [94HP] (2017MY)
Triumph Street Triple 765 R (IV) 765cc (E5) [118HP] (2020MY)
Triumph Tiger 1200 GT (I) 1160cc (E5) [148HP] (2021MY)
This new protocol is available for the following software packages:
OBD
FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
FLS0.5M – SW Flex Full Master
FLS0.5S – SW Flex Full Slave
FLS0.13M – SW Flex Bikes OBD/Bench/Boot Master
FLS0.13S – SW Flex Bikes OBD/Bench/Boot Slave
Newly added protocols:
OBD
- Triumph Keihin KHR4 SH72531 Read/Virtual Read/Write/Checksum Calculation Maps
Writing Time
~1 minute and 20 seconds
Read Time
~60 minutes
Triumph Keihin KTKS_v1 RH850 Real Read/Write/Checksum Calculation Maps
