Version 8.17.0.0 of Flex Out Now
Korhex enables the Boot Glitch mode for Mercedes Bosch MD1CP001 and MG1CP002 control units.
With the latest Flex update, version 8.17.0.0, Mercedes Bosch ECUs equipped with SPC5777 processors are now supported via Korhex and the EMFI – Electromagnetic Fault Injection technology.
This procedure simplifies access to the unit: no need solder the PCB nor to remove components.
Less steps, more autonomy in your workshop.
Place Korhex, follow the Flex-guided procedure and access the SPC5777 microprocessor.
To perform these operations, you need the FLS0.20 license or the Flex Full FLS0.5 configuration.
Contact our Sales Team at sales@magicmotorsport.com to discover which configuration best suits your needs, visit our shop or open a ticket here.
Key insights
Mercedes Bosch MD1CP001 – SPC5777
Mercedes Bosch MG1CP002 – SPC5777
Working Mode: Boot Glitch
Memories: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Backup
Licenses: FLS0.20M/S – FLS0.5M/S
Connect/Glitch Time: ~ 40 seconds
Reading Time: ~ 2 minutes
Writing Time: ~ 2 minutes
Some of the supported vehicles
Mercedes A-Class (IV) W177 (2021MY) 2.0L 220d 16v 187HP
Mercedes GLA-Class (II) H247 (2022MY) 2.0L 200d 16v 148HP
Mercedes Vito (III) W447 (2021MY) 2.0L 116 CDI 16v 161HP
Mercedes A-Class (IV) W177 (2021MY) 2.0L 45 AMG 16v 382HP
Mercedes CLE-Class (I) C236 (2023MY) 3.0L 53 AMG 24v MHEV 465HP
