Solutions for DCU17PC43 (2021)

Version 6.60.0.0 of Flex out now

Download the last update of Flex and program Adblue Bosch DCU17PC43 control units in Bench and Boot.

Thanks to the version 6.60.0.0 you will have access to Flash and EEPROM memories of new-production units (from July 2020 on) installed on Ford vehicles.

In addition to optimizing urea injection parameters, it will also be possible to restore the damaged unit by writing memories content on a working unit, once the full backup is made.

Some of the supported vehicles:

• Ford Mondeo TDCI 2.0L 140PS
• Ford Ranger TCDI 2.0L 210PS
• Ford Transit 2.0L TCDI 105PS

This new protocol is available for the following software packages:

Bench

• FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
• FLS0.5M – SW Flex Full Master
• FLS0.5M – SW Flex Full Slave
• FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
• FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave

Boot

• FLS0.5M – SW Flex Full Master
• FLS0.5M – SW Flex Full Slave
• FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
• FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave

Newly added protocols:

(BENCH)

• Ford Bosch DCU17PC43 (2021) TC1724N Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup

 Reading Time: ~ 2 minutes         Writing Time: ~ 1 minute and 30 seconds

(BOOT)

• Ford Bosch DCU17PC43 (2021) TC1724N Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup

 Reading Time: ~ 2 minutes         Writing Time: ~ 1 minute and 30 seconds

Bug Fixes:

• Added new CRC type for Mitsubishi Denso SH72543
• Added new CRC type for Kia/Hyundai Siemens SIM2K-141
• Added new Seedkey type for Honda Keihin SH7058
• Added new Seedkey type or VAG Bosch MG1CS001_SPC
• Added new Seedkey type or VAG Bosch MG1CS002_TC
• Added new Seedkey type or VAG Bosch MG1CS002_SPC
• Fixed Seedkey type for VAG Bosch MED17.1.1 (Lamborghini and Audi R8 cases)

Click here to discover the full list of supported vehicles.
