ECU and TCU programming course in Miami, Florida

Magicmotorsport, in partnership with UHS Hardware, is organising a professional meeting about products, solutions, and services to make working in mechatronic workshops easier and faster.

A training course about the programming of engine and transmission control units with Flex, about connection modes to work with ECUs and TCUs, StageX the vehicle recalibration software, discovering the Helpdesk platform and its services. Moreover, accessories and products will be presented, such as the Dynomag line and the new MAG-CX3, the CNC milling machine.

Register now to meet the Magicmotorsport team in person, the technical-sales department will train the attendees in partnership with UHS Hardware staff.

Program summary:

10 – 10.45
Basics Introduction (ECU / TCU/PCM)
ECU: What they are
ECU: what they do
ECU: how they work
ECU knowledge: ECU/TCU/PCM internal architecture

10.45 – 11.15
Flex and Flexbox Tool
FlexBox Diagnostic functions (FLX2.14)
Flex Datalogger Function

11.15 – 11.30
Communication Methods
Control unit programming methods
Protections and verification systems (Antituning, CRC, RSA)

11.30 – 11.45
Flex Software: Master – Slave
Master vs Slave

11.45 – 12.15
Tickets and Services
Chat, Vehicle Lists and Helpdesk

12.15 – 12.30
Tuning & Repair

12:30 – 13:30 Light Lunch

13:30 – 17:00

13.30 – 13.40
How to read/write an ECU ?
Practical example :
13.40 – 14.00
via BENCH – MEDG17.0 (F-150, Mustang 2.3 EcoBoost)
14.00 – 14.20
via BOOT – EMS24xx (Ford Mustang Up to 5000 V8)
14.20 – 14.40
via JTAG – Denso GEN 3 ECU (Toyota)
14.40 – 15.00
via BDM – Bosch EDC16 (BMW 5 – Series)

15.00 – 15.10
How to read/write a TCU ?
15.10 – 15.30
via BENCH – Delco 6T30 (Chevrolet, GMC, Buick, Ford)
15.30 – 15.50
via BENCH – Bosch 8HP76 (BMW Gxx, RR)

15.50 – 16.10
StageX (Basic functionality)

16.10 – 16.40
Presentation Accessories and other product lines
DynoLine ( DynoMag – DynoHub – DynoRoad)
CNC Machine

16.40 – 17.00
Q&A
